316 Stainless Steel Coil
316 stainless steel also contains 2-3% molybdenum, in addition to iron, chromium and nickel. The addition of molybdenum significantly improves the performance of 316 stainless steel in certain corrosive environments, especially those containing chlorides. 316 stainless steel is more commonly used in situations requiring higher corrosion resistance.
Inquiry Now →

PRODUCT DESCRIPTION


316 Stainless Steel Coil Description

316 stainless steel coil is an ideal option in the stainless industry for a number of key reasons. Grade 316 is the standard molybdenum-bearing austenitic grade, which is highly resistant to pitting and crevice corrosion in chloride environments. So 316 stainless steel is more commonly used in situations where higher corrosion resistance is needed. For example, in marine engineering, 316 stainless steel is often used to manufacture ship parts, subsea pipelines, offshore platforms and other facilities. In the chemical industry, it is also commonly used to manufacture equipment such as storage tanks, reactors and pipelines. In addition, in the medical field, 316 stainless steel is also widely used to manufacture medical devices and implants due to its excellent biocompatibility and corrosion resistance.

Product Parameters

Product Name316 Stainless Steel Coil
TypeSteel Coil
Thickness2.5mm-10.0mm
Length2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc.
Width610mm-2000mm
StandardASTM, AISI, JIS, GB, DIN, EN, etc.
SurfaceBA, 2B, NO.1, NO.4, 4K, HL, 8K, etc.
Scope of Application

Widely used in high temperature and electrical industry, medical equipment construction, chemical, food industry, agriculture and ship parts, food and beverage packaging,

Kitchen supplies, trains, airplanes, conveyor belts, vehicles, bolts, nuts, springs and screens, etc.

CertificateISO, SGS, BV, etc.
Production TechnologyHot Rolling, Cold Rolling
Edge ProcessingHot Rolling, Cold Rolling

Chemical Composition

CSiMnCrNiSPMo
≤ 0.03≤ 0.75≤ 2.016.0~18.010.0~14.0≤ 0.03≤ 0.0452.0-3.0

Mechanical Properties

Tensile Strength Kb (MPa)Yield Strength σ0.2 (MPa)Elongation D5 (%)Hardness
480177≥ 40≤ 187HB;≤ 90HRB;≤ 200HV

Physical Performance

Density(g/cm³)Modulus of Elasticity(Gpa)Coefficient of Thermal Expansion(10-6/°C)Coefficient of Thermal Conductivity(W/m*K)Resistivity(ΜΩ. cm)
7.9919316.016.274

Surface Selection
